HP-1400C DC24V DC compressor

  • Motor power：0.55 Kw
  • Rated voltage：24V/48v
  • Rated flow：8.4 m3/h
  • Rated current：22.0/11.0 A
  • Maximum blowing force：2000 mBar
  • Noise level：60 dB(A)
  • Product weight：8.5 Kg
  • Industry application：
    Vacuum packaging
Online Consultation Wangwang Customer Service

Product Description：Ultra-low vacuum, ultra-low silent, lightweight, beautiful appearance, simple structure, easy maintenance, completely oil-free and easier to maintain.

Welcome to call us for consultation：4006 112 722
ProjectStandard
Rated voltage/frequency VDC 24V/48V (can be made as required)
Input power W≤550W 22A
Maximum air flow m³/h≤7.2m³/h(120L/min)
Rated working pressure KPa200 KPa(2 kgf/cm2)
Maximum working pressure KPa200 KPa(2 kgf)
Noise dB(A)≤ 60 dB(A)
Amplitude(mm)
Operating ambient temperature ℃5-40 ℃
Insulation levelB
Cold state insulation resistance(normal)MΩ≥100MΩ
Withstand voltage strength1500V/50Hz 1min No breakdown
Thermal protector℃Automatic reset 130±5℃
Weight8.5Kg
Installation dimensionsL203*W112mm(Installation foot holes￠5mm)
Overall dimensionsL244*W128*H186mm
restart pressure0KPa
Intake and exhaust nozzle outer diameter1/4-19PT pipe thread
